Mic-W i436 Kit Package

The i436 is a calibrated measurement microphone that complies with the IEC 61672 Class 2 sound level meter standard. The sensitivity and frequency response of each individual i436 microphone is calibrated at the factory before shipping. With the i436 and a dedicated App, an iPhone or iPad can be turned into a sound pressure level (SPL) meter, or a real-time analyzer (RTA) for time and frequency domain measurements.

The omnidirectional microphone offers outstanding performance in a small package. Durable and easily carried in the pocket, the i436 measures speech, instruments and other live sounds accurately and without distortion – all on a mobile device.

• Type
• Electret Condenser

• Capsule diameter
• 7.0mm (Could be calibrated)

• Principe of operation: Pressure

• Polar Pattern: Omni Directional

• Sensitivity(±3dB):  -44dB(6.3mV/Pa)

• Frequency Response:  20Hz~20kHz

• S/N ratio:  More than 62dB

• Impedance:  Less than 2.2k Ohm

• Power Source:  Plug and play

• Operating Temperature:  -20℃~+50℃

• Length:  50mm

• Weight:  8g

• Connector:  3.5mm 4-Pole headset interface
